Noshok 627 Series Intrinsically Safe Submersible Liquid Level Transmitters

627 Series Intrinsically Safe Submersible Liquid Level Transmitters



• Ranges from 0 inH2O to 50 inH2O through 0 psig to 350 psig
• Current output
• 316 stainless and 17-4PH steel wetted parts
• Factory Mutual and Canadian Standards Association approved
• CE compliant to suppress RFI, EMI and ESD

NOSHOK 627 Series transmitters are Factory Mutual and
Canadian Standards Association approved for use in
hazardous location applications as follows:

• Intrinsically Safe, entity approval for Class I, II and III, Division 1,
  Groups A, B, C, D, E, F, and G; and Class I, Zone 0 Aex ia IIC
• Dust ignition-proof for Class II and III, Division 1, Groups E, F, and G
• Non-incendive for Class I, Division 2, Groups A, B, C, and D
• FMRC 3600, 3610, 3611, 3810 (including supplement #1)
• ISA-S12.0.01, IEC 60529 (including amendment #1)
• CE compliant with pressure equipment directive 97/23EC







ORDERING INFORMATION

SERIES	627
PRESSURE RANGES	50inH2O	0 inH2O to 50 inH2O	5	0 psig to 5 psig (11.5 ftH2O)	100	0 psig to 100 psig (230.7 ftH2O)
	100inH2O	0 inH2O to 100 inH2O	10	0 psig to 10 psig (23.1 ftH2O)	160	0 psig to 160 psig (369.1 ftH2O)
	150inH2O	0 inH2O to 150 inH2O	15	0 psig to 15 psig (34.6 ftH2O)	200	0 psig to 200 psig (461.3 ftH2O)
	250inH2O	0 inH2O to 250 inH2O	25	0 psig to 25 psig (57.7 ftH2O)	300	0 psig to 300 psig (692.3 ftH2O)
	400inH2O	0 inH2O to 400 inH2O	30	0 psig to 30 psig (69.2 ftH2O)	350	0 psig to 350 psig (807.3 ftH2O)
			60	0 psig to 60 psig (138.4 ftH2O)
	psig = gauge pressure       inH2O = inches of water       ftH2O = feet of water       Other ranges available on special request.
ACCURACIES	1	± 0.25% full scale (BFSL)	2	± 0.125% full scale (BFSL) on ≥ 150 inH2O
OUTPUT SIGNAL	1	4 mA to 20 mA, 2-wire
PROCESS CONNECTIONS	N	Stainless steel nosecone	W	Stainless steel weighted nosecone (1.1 lbs.)
	T	NPT adapter, 1/2″ NPT male outer thread with 1/4″ NPT female inner thread attached to transmitter process connection with straight thread and o-ring seal
ELECTRICAL CONNECTIONS	XX	Standard Polyurethane cable
	38-XX	Optional FEP cable	NOTE: XX=length of cable in feet
OPTIONS	CC	Cable Clamp	FE	Filter Element
	DC	Desiccant Cartridge
