100 Series Mini, Hard Seat Needle Valves

NOSHOK-101-MFB-HL1 1/8 NPT, Male x Female Brass Mini T Handle, Hard Seat Mini Valve

NOSHOK 151-MMC 1/8″ NPT Male – Male Steel Soft Tip Mini Valve

• Compact size valve built for maximum durability and robust performance
  in the toughest applications
• 100% helium leak tested to 1 x 10^-4 ml/s for guaranteed performance
  and reliability
• Hard seat valves have a maximum pressure of 10,000 psi for stainless
  steel and steel models; 6,000 psi for brass
• Available in zinc-nickel plated steel, electropolished stainless steel,
  and brass
• FKM o-ring seal and PTFE back-up ring below the stem threads to
  protect from corrosion and galling; PTFE or Grafoil^® packing optional
• All stems are 316 stainless steel
• All stem threads are rolled for strength and ease of operation
• Patented body-to-bonnet, metal-to-metal seal is designed to significantly
  increase the pressure range of the valve (U.S. Patent 7,758,014)

To meet all of your specific application requirements, the following additional options are available for these needle valves. To order all or any of these options, simply add them to the part number as shown in the diagram below.
NOTE 1: The example shown includes ALL possible additional options. Please include ONLY the options required for your application when building your part number. (EXAMPLE: 102-MFC-HL3)
NOTE 2: When a packing option is selected, an o-ring option is NOT available.

ORDERING INFORMATION – Additional Options

    Please consult your local NOSHOK Distributor or NOSHOK, Inc. for availability and delivery information.

† If a packing option is chosen, maximum pressure rating is 6,000 psi. Refer to the “Pressure vs Temperature: Packing Style with Compatible Fluid” chart.

* Other o-ring materials available on request.

Please note that the standard o-ring in all the NOSHOK mini valves is FKM and the standard handles are brass round knurled (HL3) handles, steel mini “T” handles (HL1), and 316SS mini “T” handles (HL1).

The handle material will always match the material of the valve, unless otherwise specified. For example, the round knurled (HL3) on a 102-FFB will be brass. When only the standard configuration is needed, no additional designations are necessary. Please consult the factory for special application requests.
