-32%
NOSHOK 102-EMFC 1/4 NPT, Male x Female, Extended, Steel, Hard Seat Mini Valve
NOSHOK List price: Original price was: $46.03.$32.20Current price is: $32.20.
Noshok 102-FFC-EM1-HL2 1/4 NPT, Female x Female, Steel, EPDM O-Ring, 2-1/2 T Handle, Hard Seat Mini Valve
NOSHOK List price: Original price was: $41.47.$28.95Current price is: $28.95.
Noshok 102-FFAC-EM1-PM2-HL5 1/4 NPT, Female x Female, Angle, Steel, EPDM O-Ring, Panel Mount, 1-3/4 Phenolic Handle, Hard Seat Mini Valve
Online Prices
NOSHOK List price: Original price was: $82.00.$55.76Current price is: $55.76.
102-FFAC-EM1-PM2-HL5 1/4 NPT, Female x Female, Angle, Steel, EPDM O-Ring, Panel Mount, 1-3/4 Phenolic Handle, Hard Seat Mini Valve
100 Series Mini, Hard Seat Needle Valves
Application Brochures
Oil & GasIf you are viewing on a smaller screen or with screen zoom, please use the horizontal scroll bar at the bottom of this table to see all information.
ORDERING INFORMATION
| SERIES | 1 | 100 Series, hard seat | ||||
| CONNECTION SIZES | 01 | 1/8″ NPT | 42 | 7/16″-20 UNF-2B* | ||
| 02 | 1/4″ NPT | 43 | 9/16″-18 UNF-2B* | |||
| VALVE TYPES | MMB | Male-Male, Brass | EMFC | Extended Male-Female, Steel | EMFS | Extended Male-Female, Stainless Steel |
| MFB | Male-Female, Brass | MFC | Male-Female, Steel | MFS | Male-Female, Stainless Steel | |
| EFFB | Extended Female-Female, Brass | EFFC | Extended Female-Female, Steel | EFFS | Extended Female-Female, Stainless Steel | |
| FFB | Female-Female, Brass | FFC | Female-Female, Steel | FFS | Female-Female, Stainless Steel | |
| MMAB | Male-Male Angle, Brass | MMAC | Male-Male Angle, Steel | MMAS | Male-Male Angle, Stainless Steel | |
| MFAB | Male-Female Angle, Brass | MFAC | Male-Female Angle, Steel | MFAS | Male-Female Angle, Stainless Steel | |
| FFAB | Female-Female Angle, Brass | FFAC | Female-Female Angle, Steel | FFAS | Female-Female Angle, Stainless Steel | |
| MMC | Male-Male, Steel | MMS | Male-Male, Stainless Steel | |||
* Available only on EFFB, EFFC, and EFFS valve types.
ORDERING INFORMATION – Additional Options
| PACKINGS * | P1 | PTFE | P2 | Graphite | ||
| STEM TIPS | T1 | Non-rotating (316 stainless standard) | T6 | Ball (carbide) | T8 | Ball (Monel) |
| T5 | Ball (440C stainless) | T7 | Ball (ceramic) | T9 | Non-rotating regulating (316 Stainless) | |
| O-RINGS ** | EM1 | EPDM | KZ1 | FFKM (Kalrez® 3018 or equivalent) | NB1 | NBR |
| PANEL MOUNTINGS | PM1 | Panel mount (1 nut) | PM2 | Panel mount (2 nuts) | ||
| HANDLES | HL2 | 2-1/2″ “T” | HL4 | 1-3/8″ Phenolic | ||
| HL3 | 1″ Round knurled | HL5 | 1-3/4″ Phenolic |
* If a packing option is chosen, maximum pressure rating is 6,000 psi. Refer to the “Pressure vs Temperature: Packing Style with Compatible Fluid” chart.
** Other o-ring materials available on request.
Please note that the standard o-ring in all the NOSHOK mini valves is FKM and the standard handles are brass round knurled (HL3) handles, steel mini “T” handles (HL1), and 316SS mini “T” handles (HL1).
The handle material will always match the material of the valve, unless otherwise specified. For example, the round knurled (HL3) on a 102-FFB will be brass. When only the standard configuration is needed, no additional designations are necessary. Please consult the factory for special application requests.
Options & Accessories
Description
102-FFAC-EM1-PM2-HL5 1/4 NPT, Female x Female, Angle, Steel, EPDM O-Ring, Panel Mount, 1-3/4 Phenolic Handle, Hard Seat Mini Valve
100 Series Mini, Hard Seat Needle Valves
Application Brochures
Oil & GasIf you are viewing on a smaller screen or with screen zoom, please use the horizontal scroll bar at the bottom of this table to see all information.
ORDERING INFORMATION
| SERIES | 1 | 100 Series, hard seat | ||||
| CONNECTION SIZES | 01 | 1/8″ NPT | 42 | 7/16″-20 UNF-2B* | ||
| 02 | 1/4″ NPT | 43 | 9/16″-18 UNF-2B* | |||
| VALVE TYPES | MMB | Male-Male, Brass | EMFC | Extended Male-Female, Steel | EMFS | Extended Male-Female, Stainless Steel |
| MFB | Male-Female, Brass | MFC | Male-Female, Steel | MFS | Male-Female, Stainless Steel | |
| EFFB | Extended Female-Female, Brass | EFFC | Extended Female-Female, Steel | EFFS | Extended Female-Female, Stainless Steel | |
| FFB | Female-Female, Brass | FFC | Female-Female, Steel | FFS | Female-Female, Stainless Steel | |
| MMAB | Male-Male Angle, Brass | MMAC | Male-Male Angle, Steel | MMAS | Male-Male Angle, Stainless Steel | |
| MFAB | Male-Female Angle, Brass | MFAC | Male-Female Angle, Steel | MFAS | Male-Female Angle, Stainless Steel | |
| FFAB | Female-Female Angle, Brass | FFAC | Female-Female Angle, Steel | FFAS | Female-Female Angle, Stainless Steel | |
| MMC | Male-Male, Steel | MMS | Male-Male, Stainless Steel | |||
* Available only on EFFB, EFFC, and EFFS valve types.
ORDERING INFORMATION – Additional Options
| PACKINGS * | P1 | PTFE | P2 | Graphite | ||
| STEM TIPS | T1 | Non-rotating (316 stainless standard) | T6 | Ball (carbide) | T8 | Ball (Monel) |
| T5 | Ball (440C stainless) | T7 | Ball (ceramic) | T9 | Non-rotating regulating (316 Stainless) | |
| O-RINGS ** | EM1 | EPDM | KZ1 | FFKM (Kalrez® 3018 or equivalent) | NB1 | NBR |
| PANEL MOUNTINGS | PM1 | Panel mount (1 nut) | PM2 | Panel mount (2 nuts) | ||
| HANDLES | HL2 | 2-1/2″ “T” | HL4 | 1-3/8″ Phenolic | ||
| HL3 | 1″ Round knurled | HL5 | 1-3/4″ Phenolic |
* If a packing option is chosen, maximum pressure rating is 6,000 psi. Refer to the “Pressure vs Temperature: Packing Style with Compatible Fluid” chart.
** Other o-ring materials available on request.
Please note that the standard o-ring in all the NOSHOK mini valves is FKM and the standard handles are brass round knurled (HL3) handles, steel mini “T” handles (HL1), and 316SS mini “T” handles (HL1).
The handle material will always match the material of the valve, unless otherwise specified. For example, the round knurled (HL3) on a 102-FFB will be brass. When only the standard configuration is needed, no additional designations are necessary. Please consult the factory for special application requests.
