25-901-30/30-psi/kPa-DRY gauge-1/4 NPT Bottom Conn, 2.5 SS -noshok

1/4 NPT Bottom Conn, 2.5 SS Case Dry Gauge

• Pressure Gauge, 2.5″ 304SS Case, Copper Alloy Internals, 30/30 psi/kPa, 1/4 NPT Male Bottom Conn, Dry Gauge

• 	SERIES	SPECIFICATIONS
  Pressure ranges	900 Series (all)	Vacuum and compound ranges through 0 psi to 15,000 psi***
  Accuracy	15-910, 15-910, 15-911	±2.5% full scale
  	20-901, 20-911, 25-900, 25-910, 25-901, 25-911	±1.6% full scale
  	40-901, 40-911	±1% full scale
  Temperature ranges*	900 Series (all)	Media -4 °F to 140 °F (-20 °C to 60 °C) Glycerin fill -40 °F to 140 °F (-40 °C to 60 °C) Special fill Ambient -4 °F to 140 °F (-20 °C to 60 °C) Glycerin fill -40 °F to 140 °F (-40 °C to 60 °C) Special fill
  Measuring element	900 Series (up to 600 psi)	Copper alloy C-Type Bourdon tube
  	900 Series (> 600 psi)	Coiled safety tube
  Connection	15-910, 15-901, 15-911	1/8″ NPT, brass
  	20-901, 20-911, 25-900, 25-910, 25-901, 25-911	1/4″ NPT or 7/16”-20 adjustable, brass
  	40-901, 40-911	1/4″ NPT, brass 1/2″ NPT, brass
  Case	15-910, 25-900, 25-910	ABS with safety relief plug
  	15-901, 15-911, 20-901, 20-911, 25-901, 25-911, 40-901, 40-911	304 Stainless Steel
  Bezel	15-901, 15-911, 20-901, 20-911, 25-901, 25-911, 40-901, 40-911	304 Stainless Steel
  Lens	15-910, 25-900, 25-910	Acrylic; ultrasonically welded to the case
  	15-901, 15-911, 20-901, 20-911, 25-901, 25-911, 40-901	Polycarbonate
  Pointer	15-901,15-910, 15-911, 20-901, 20-911, 25-900, 25-910, 25-901, 25-911	Molded plastic
  	40-901, 40-911	Balanced aluminum, black finish
  Dial	15-910, 25-900, 25-910, 25-901, 25-911	Molded plastic, white background with black primary scale & red secondary scale. UV resistant
  	40-901, 40-911	Aluminum, white background with black primary scale & red secondary scale. UV resistant.
  Movement	15-901,15-910, 15-911, 20-901, 20-911, 25-900, 25-910, 25-901, 25-911	Brass and nylon with highly polished bearing surfaces
  Fill liquid**	900 Series (all)	Glycerin

  * For every 18 °F (10 °C) shift in temperature from which the gauge is calibrated, the user can experience up to ±0.4% additional error.
  ** See gauge fill options
  *** See Ordering Information
