NOSHOK PGE20-3000psig-1-2 General Purpose Digital Gauge-1/4 NPT male

Part Number: PGE20-3000psig-1-2

Original price was: $645.59.Current price is: $499.99.

10 in stock

Avalable For immediate Delivery
Warranty: 3 YEARS
NEED TO PURCHASE IN BULK ?
Custom-Built NOSHOK Gauges Available!
Add to wishlist
Compare

NOSHOK PGE20-3000psig-1-2-ST8 General Purpose Digital Gauge

General Purpose Digital Pressure Gauge, 0 to 3000 psi gauge, ±0.50% of full, including non-linearity, hysteresis, zero offset, and end point deviation per IEC 61298-2 at reference conditions, 1/4 NPT male

RIES PGE20
PRESSURE
RANGES		 15psiv -15 psig to 0 psig 70psig 0 psig to 70 psig 1500psig 0 psig to 1,500 psig 5psia 0 psia to 5 psia
15psic  -15 psig to 15psig 100psig  0 psig to 100 psig 2000psig 0 psig to 2,000 psig 15psia 0 psia to 15 psia
160psic -15 psig to 160 psig 150psig 0 psig to 150 psig 3000psig 0 psig to 3,000 psig 30psia 0 psia to 30 psia
200psic -15 psig to 200 psig 200psig 0 psig to 200 psig 4000psig 0 psig to 4,000 psig 70psia 0 psia to 70 psia
300psic -15 psig to 300 psig 300psig 0 psig to 300 psig 5000psig 0 psig to 5,000 psig 120psia 0 psia to 120 psia
600psic -15 psig to 600 psig 400psig 0 psig to 400 psig 6000psig 0 psig to 6,000 psig 150psia 0 psia to 150 psia
5psig 0 psig to 5psig 500psig 0 psig to 500 psig 7500psig 0 psig to 7,500 psig 300psia 0 psia to 300 psia
10psig 0 psig to 10 psig 600psig 0 psig to 600 psig 10000psig 0 psig to 10,000 psig 500psia 0 psia to 500 psia
15psig 0 psig to 15 psig 750psig 0 psig to 750 psig 15000psig 0 psig to 15,000 psig
30psig 0 psig to 30psig 1000psig 0 psig to 1,000 psig
 psiv=vacuum gauge        psic=compound pressure       psig=gauge pressure        psia=absolute pressure        Other ranges available on request
ACCURACIES 1 ±0.5% Full Scale  2  ±0.25% Full Scale*
PROCESS CONNECTION 2 1/4″ NPT male
OPTIONS DL Integrated Data Logger RCP Rubber Case Protector ST8 SS Threaded Orifice

Please consult your local NOSHOK Distributor or NOSHOK, Inc. for availability and delivery information.

* Includes additional units of measure, level, density and delay.

Description

NOSHOK PGE20-3000psig-1-2-ST8 General Purpose Digital Gauge

General Purpose Digital Pressure Gauge, 0 to 3000 psi gauge, ±0.50% of full, including non-linearity, hysteresis, zero offset, and end point deviation per IEC 61298-2 at reference conditions, 1/4 NPT male

RIES PGE20
PRESSURE
RANGES		 15psiv -15 psig to 0 psig 70psig 0 psig to 70 psig 1500psig 0 psig to 1,500 psig 5psia 0 psia to 5 psia
15psic  -15 psig to 15psig 100psig  0 psig to 100 psig 2000psig 0 psig to 2,000 psig 15psia 0 psia to 15 psia
160psic -15 psig to 160 psig 150psig 0 psig to 150 psig 3000psig 0 psig to 3,000 psig 30psia 0 psia to 30 psia
200psic -15 psig to 200 psig 200psig 0 psig to 200 psig 4000psig 0 psig to 4,000 psig 70psia 0 psia to 70 psia
300psic -15 psig to 300 psig 300psig 0 psig to 300 psig 5000psig 0 psig to 5,000 psig 120psia 0 psia to 120 psia
600psic -15 psig to 600 psig 400psig 0 psig to 400 psig 6000psig 0 psig to 6,000 psig 150psia 0 psia to 150 psia
5psig 0 psig to 5psig 500psig 0 psig to 500 psig 7500psig 0 psig to 7,500 psig 300psia 0 psia to 300 psia
10psig 0 psig to 10 psig 600psig 0 psig to 600 psig 10000psig 0 psig to 10,000 psig 500psia 0 psia to 500 psia
15psig 0 psig to 15 psig 750psig 0 psig to 750 psig 15000psig 0 psig to 15,000 psig
30psig 0 psig to 30psig 1000psig 0 psig to 1,000 psig
 psiv=vacuum gauge        psic=compound pressure       psig=gauge pressure        psia=absolute pressure        Other ranges available on request
ACCURACIES 1 ±0.5% Full Scale  2  ±0.25% Full Scale*
PROCESS CONNECTION 2 1/4″ NPT male
OPTIONS DL Integrated Data Logger RCP Rubber Case Protector ST8 SS Threaded Orifice

Please consult your local NOSHOK Distributor or NOSHOK, Inc. for availability and delivery information.

* Includes additional units of measure, level, density and delay.
